GADITES GYN40-AC 4P Type 2+3 Surge Protective Device | 275V AC SPD | 20kA In | 40kA Imax | Up ≤1.2kV | Lightning & Surge Protection | DIN Rail Mount | 3 Phase + Neutral Protection | Replaceable Modules
- ADVANCED TYPE 2 + TYPE 3 SURGE PROTECTION
Protects electrical and electronic equipment from lightning-induced surges, switching transients, grid disturbances and voltage spikes. Combined Type 2 + Type 3 protection provides enhanced safety for sensitive equipment.
- HIGH 40kA SURGE CAPACITY
Engineered with 20kA nominal discharge current and 40kA maximum discharge capacity to safely divert dangerous surge currents before they damage connected equipment.
LOW ≤1.2kV PROTECTION LEVEL
Limits dangerous overvoltages to a low residual voltage level, helping protect solar inverters, PLC systems, CCTV cameras, computers, networking equipment and industrial automation systems.
COMPLETE 4 POLE PROTECTION
Provides protection for all conductors including L1, L2, L3 and Neutral. Suitable for 3-phase electrical distribution boards, industrial panels, commercial buildings and solar AC applications.
Features plug-in replaceable protection modules and visual status indicators for easy maintenance, reduced downtime and lower replacement costs.
PRODUCT DESCRIPTION
Professional Lightning & Surge Protection for Critical Electrical Systems
The GADITES GYN40-AC 4 Pole Type 2+3 Surge Protective Device is engineered to protect valuable electrical and electronic equipment against lightning surges, switching transients and power disturbances.
Designed with a 40kA maximum discharge capacity, 20kA nominal discharge current and low protection level of ≤1.2kV, the device rapidly diverts harmful surge energy to earth before it reaches connected equipment.
The modular plug-in design allows quick cartridge replacement while the visual status indicator enables easy monitoring of protection status.
Suitable for residential, commercial, industrial and renewable energy applications.
Protects:
✔ Solar Inverters
✔ Industrial PLC Systems
✔ CCTV Systems
✔ Computers & Servers
✔ Automation Panels
✔ Telecommunication Equipment
✔ Smart Homes
✔ Commercial Buildings
✔ Hospitals
✔ Data Centers
TECHNICAL SPECIFICATIONS
Parameter Value Model GYN40-AC SPD Type Type 2 + Type 3 Pole Configuration 4P (3P+N) Uc 275V AC In 20kA Imax 40kA Uoc 6kV Up ≤1.2kV Response Time ≤25ns Mounting DIN Rail Status Indicator Green / Red Module Type Plug-In Replaceable Application AC Distribution Systems
